SOIC-24 Analog To Digital Converter IC 24 Bit Sigma Delta ADC Converter IC AD7714ARZ-5

Product Categories
Walton Electronics Co., Ltd.
Contact Now

SOIC-24 Analog To Digital Converter IC 24 Bit Sigma Delta ADC Converter IC AD7714ARZ-5

  • 1
  • 2

Brand Name : original

Model Number : AD7714ARZ-5

Certification : ISO9001:2015standard

Place of Origin : original

MOQ : 10pcs

Price : Contact us to win best offer

Payment Terms : L/C, T/T, Western Union,PayPal

Supply Ability : 10000pcs/months

Delivery Time : 1-3 workdays

Packaging Details : Standard

Mounting Style : SMD/SMT

Package / Case : SOIC-24

Number of Channels : 8 Channel

Interface Type : I2C

Packaging : Tube

Contact Now

Semiconductor Data Digital Converters ADC 24-BIT SIGMA DELTA A/D IC AD7714ARZ-5

GENERAL DESCRIPTION†

The AD7714 is a complete analog front end for low-frequency measurement applications. The device accepts low level signals directly from a transducer and outputs a serial digital word. It employs a sigma-delta conversion technique to realize up to 24 bits of no missing codes performance. The input signal is applied to a proprietary programmable gain front end based around an analog modulator. The modulator output is processed by an onchip digital filter. The first notch of this digital filter can be programmed via the on-chip control register allowing adjustment of the filter cutoff and settling time.

The part features three differential analog inputs (which can also be configured as five pseudo-differential analog inputs) as well as a differential reference input. It operates from a single supply (+3␣ V or +5␣ V). The AD7714 thus performs all signal conditioning and conversion for a system consisting of up to five channels.

The AD7714 is ideal for use in smart, microcontroller- or DSPbased systems. It features a serial interface that can be configured

SOIC-24 Analog To Digital Converter IC 24 Bit Sigma Delta ADC Converter IC AD7714ARZ-5

SOIC-24 Analog To Digital Converter IC 24 Bit Sigma Delta ADC Converter IC AD7714ARZ-5

Product Category: Analog to Digital Converters - ADC
AD7714
SMD/SMT
SOIC-24
24 bit
5 Channel
SPI
1 kS/s
Differential/Pseudo-Differential
Sigma-Delta
4.75 V to 5.25 V
3 V to 5.25 V
- 40 C
+ 85 C
Tube
Development Kit: EVAL-AD7714-3EBZ
Gain Error: +/- 0.003 %FSR
Height: 2.35 mm
INL - Integral Nonlinearity: +/- 0.0015 % FSR
Input Voltage: 2.5 V, +/- 2.5 V
Length: 15.6 mm
Number of ADC Inputs: 4 Input/3 Input
Number of Converters: 1 Converter
Operating Supply Voltage: 5 V
Pd - Power Dissipation: 7 mW
Power Consumption: 5 mW
Product Type: ADCs - Analog to Digital Converters
Reference Type: External, Internal
Reference Voltage: 2.5 V
Sample and Hold: No
31
Subcategory: Data Converter ICs
Supply Voltage - Max: 5 V
Supply Voltage - Min: 5 V
Width: 7.6 mm
Unit Weight: 0.038731 oz

Company Advantages

1. We can offer products according to customer's BOM list. One stop purchase.
2. All kinds of chips, various types and complete brands.
3.More than 15years for sales original IC parts.
4. Comprehensive customer service: from customer consultation to after sales service.
5. Walton can offer sample for free , but client have to pay shipping cost. Contact us if needed.


Product Tags:

SMT Analog to Digital Converter IC



SOIC-24 Analog to Digital Converter IC



AD7714ARZ-5 ADC converter IC


Quality SOIC-24 Analog To Digital Converter IC 24 Bit Sigma Delta ADC Converter IC AD7714ARZ-5 wholesale

SOIC-24 Analog To Digital Converter IC 24 Bit Sigma Delta ADC Converter IC AD7714ARZ-5 Images
