LXAC-1850 High Power LEDs White Emitters Lighting Opto-electronics
The LUXEON H50-2 delivers superior efficacy, color performance and reliability in a high voltage architecture that minimizes driver requirements making it an ideal solution for space constrained and cost sensitive retrofit bulbs and luminaires. With exceptional color stability over temperature and current, LUXEON H50-2 simplifies design while providing superior quality of light. This document contains the performance data and technical information needed to design and develop LUXEON H50-2 based solutions.
Features and Benefits
• Enables design of small socket and cost sensitive luminaires with simple, efficient and small size driver
• Is binned at 85°C and 40 mA with 3 and 5 SDCM color binning. 50V 2 watt LED flexibly supports 110V and 220V solutions.
• Exceeds ENERGY STAR lumen maintenance requirements
• Delivers real-world in application performance and reliability
| Product Attribute | Attribute Value |
| Product Category: | High Power LEDs - White |
| Product: | White LEDs |
| Mounting Style: | SMD/SMT |
| Package/Case: | 3737 |
| Illumination Colour: | Cool White |
| Wavelength/Colour Temperature: | 5000 K |
| Luminous Intensity: | - |
| Luminous Flux/Radiant Flux: | 175 lm |
| Colour Rendering Index - CRI: | 80 |
| Viewing Angle: | 110 deg |
| If - Forward Current: | 40 mA |
| Vf - Forward Voltage: | 50 V |
| Power Rating: | 2 W |
| Length: | 3.7 mm |
| Width: | 3.7 mm |
| Height: | 2.018 mm |
| Minimum Operating Temperature: | - 40 C |
| Maximum Operating Temperature: | + 118 C |
| Lens Dimensions: | 3 mm |
| Lens Shape: | Dome |
| Lens Transparency: | Water Clear |
| Series: | LUXEON H50-2 |
| Packaging: | Reel |
| LED Size: | 3.7 mm x 3.7 mm x 2.018 mm |
| Product Type: | LED - High Power |
| Factory Pack Quantity: | 1000 |
| Subcategory: | LEDs |
| Tradename: | LUXEON |
